1. On-line full-automatic depaneling, automatic loading automatic depaneling automatic discharging, realize unmanned operation.
2. Dual-axis dual-platform simultaneous depaneling, doubling the capacity efficiency.
3. Applicable to all V-slot PCBA board slitting
4. Small stress of depaneling, preventing damage to SMT parts and cracking of solder joints
5. Splitting machine has obtained a number of invention patents, utility model patent certificates.
6. Export CE certification, leading technology, excellent quality, industry benchmark.
7. Undertake a variety of non-standard fully automatic sub-boarding machine
| Specification | |
| Partitioning accuracy: 0.05mm | Equipment Source: AC220/3KW |
| Cutting speed: 300mm/s | Woking Air pressure: 0.4-0.8Mpa |
| Split board thickness: 0.6~3.0mm | Man-machine operation and data storage: industrial computer |
| Split board maximum size: 350mm*350mm | Host Size : 1600*1200*1800 (L X H X D)mm |
| operation interface: Chinese/English interface | Operation Systems:Windows7 |
| Machine Weight: 1000kg | Power: 2KW |
