PCB Separator V Groove PCB Depaneling V Cut PCB Depanelizer Description:
In both units, CWVC-1S and CWVC-1SJ, the separation between the upper guide and the lower guide is adjustable by means of a rotary knob. In this way it is ensured that the PCB is fed only through the pre-scored groove.
The pre-scored grooves on the PCBs can be interrupted by cuts with a length of up to approx. 5mm
Tests have revealed that the greater the separation between the circular knives, the smaller the tension produced during the separation process.
Pre-Scored PCB Separator V Groove PCB Depaneling V Cut PCB Depanelizer
1. Guide can be adjusted vertically to suit different PCB thickness.
2. Clearance between the circular blades can be precisely adjusted with the knob.
3. Upper and lower circular blades can be re-used after regrinding.
4. Shape and sizes of the circular blades can be made according to customer's specifications.
Specifications:
|
Model: |
CWVC-1S |
|
Size: |
420 x 280 x 400mm |
|
The Longest Minimize: |
unlimited |
|
Minimize Speed: |
0-400mm/s |
|
Minimize Thickness: |
1.0-3.5mm |
|
Machine Weight: |
25Kg |
Competitive Advantage:
1. CWVC-1S Pcb depanelizer original manufacturers, price concessions
2. Day technical support services
3. Limit the handling of complaints, half an hour back to customers
4. Depanel Experts, the provision of professional PCB sub-programme
For a list of Standard Steel Blades
